Place of Origin: | China, Shanghai |
Brand Name: | Osign |
Model Number: | OSIGN |
Minimum Order Quantity: | 100pcs |
---|---|
Price: | Negotiable |
Packaging Details: | carton box and pallet |
Delivery Time: | 1-3 Days |
Payment Terms: | T/T, money gram, western union, L/C, D/P |
Supply Ability: | 500000 Rolls Per Week |
Material: | PVC | Thickness: | 1-30mm |
---|---|---|---|
Size: | 1220*2440mm | Density: | 0.45-0.9 G/cm3 |
Width: | 1m, 1.22m, 1.56m, 2.05m | Color: | White, Black, Etc. |
Port: | Shanghai | ||
High Light: | pvc rigid foam sheet,pvc foam core board |
1. Specification:
(1). Thickness: from 1mm to 30mm
(2). Size:
standard size: 1.22m x 2.44m (4ft x 8ft).
Available width: 1m, 1.22m, 1.56m, 2.05m
Available length: any
(3). Density: from 0.45 to 0.9 kg/m3
(4). Suit for: Solvent, Eco-solvent, UV printing, Screen printing
Properties | Unit | Average Result |
Apparent Density | g/cm3 | 0.4~0.9 |
Tensile Strength | Mpa | ≥13 |
Elogation at break | % | ≥10 |
Bending Strength | Mpa | ≥20 |
Flexual Modulus | Mpa | 600~1200 |
Vicat Softening point | °C | ≥70 |
Water absorption | % | ≤1.0 |
Dimensional stability | % | ±2.0 |
Compressive Strength | Mpa | >3 |
Compressive Stress at 30% | Mpa | > 7 |
Choppy Impact Strength | Value | ≥12 |
Shore D Hardness | KJ/m2 | ≥50 |
Fire resistance | Seconds | Self-extinguishing less than 5 seconds |
Tolerances: 1) ±5mm on width. 2) ±10mm on length. 3) ±5% on sheet thickness |
