| Place of Origin: | China, Shanghai |
| Brand Name: | Osign |
| Model Number: | 1220*2440 |
| Minimum Order Quantity: | 100pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | carton box and pallet |
| Delivery Time: | 1-3 Days |
| Payment Terms: | T/T, money gram, western union, L/C, D/P |
| Supply Ability: | 500000 Rolls Per Week |
| Usage: | Outdoor | Function: | Fireproof |
|---|---|---|---|
| Surface Treatment: | PE Coated | Coated: | PE |
| Color: | Customer's Requirements | Width: | 1220mm |
| Length: | 2440mm | Standard Size: | 1220mm*2440mm |
| Product Name: | Exterior Wall Cladding | Panel Thickness: | 3.0mm/4.0mm |
| Aluminium Thickness: | 0.03-0.5mm | Application: | Decorative Material |
| Port: | Shanghai | ||
| High Light: | aluminum composite board,aluminum plastic composite panel |
||
aluminum composite panel marble finish Aluminium Composite Panel acp with high quality aluminum composite panel/ ACP
Main Product List:
Dimensions of Aluminum Composite Panels: Thickness: 3 to 4mm Width: 1,220, 1,250, 1,270, 1,500, 1,550 and 1,570mm Length: 2,440mm and customized length within 5,000mm</ul> Weight: 5.6kg/Sqm based on 4mm thick Standard size: 1,220 x 2,440mm (nonstandard sizes are available according to your requirements)
Specifications: Material: The front side use aluminum-alloy sheet coated with flour-carbon resin (PVDF) roasting painting Core: nontoxic polyethylene Back side: aluminum-alloy sheet coated with polyester resin painting Surface finish: treated with PVDF and PE resin rolling roasting coating Surface coating thickness: 30um Aluminum-alloy sheet thickness: 0.08,0.1, 0.12, 0.15, 0.18, 0.2, 0.3, 0.4, 0.45 and 0.5mm Color: purple red (26 standard colors, hundreds of different colors and special colors are available according to customers' request)
Characteristics: Lightweight, flat surface and high strength lightweight, excellent rigidity, good impact resistance Excellent in heat insulation, sound insulation, fire-, acid-, alkali-, weather-resistant and non-resonance Can be easy installation, easy processing and easy maintenance Bright, elegant and magnificent, it fits various designs Hylar 5,000 PVDF resin features strong chemical-resistant, unique colors can be easily maintained
Applications: Can be widely used in galleries, exhibitions, saloons, stores, offices, banks, hotels, restaurants and apartments Other kinds of buildings as an ideal decorative materials for interior and exterior of building Decoration of interior walls, ceilings, bathrooms, kitchens and balconies and shops door, billboards, signboards, tunnel and subway interiors Telephone booths, vehicle bodies, yachts and industrial usage Quality standard: according to GB/T 17748-1999 and SGS KV-07-04992X standards
